Description
To optimize steering geometry once lifted a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle.
Specifications:
| Description_ASC | Removal of the factory leaf spring block is required. The net rear lift will vary depending on the height of the factory block but will result in a level stance. |
| Description_ASC | If equipped with a 2-piece rear driveshaft a Carrier Bearing Drop Kit may be required (BDS123402) |
| Description_ASC | Front exhaust modification may be required to clear front drive shaft (Gas Only) |
| Description_ASC | Torque wrench capable of 405 ft-lbs required. |
| Description_ASC | 37 x 12.50 tires may require minor trimming. |
| Description_DES | 17-19 F350 DRW 4in. Radius Arm Lift Kit – Gas – NX2 |
| Description_EXT | 17-19 F350 DRW 4in. Radius Arm Lift Kit – Gas – NX2 |
| Description_FAB | Easy 100% Bolt-on installation |
| Description_FAB | Pro-Ride dual rate coil springs provide a remarkable ride through any terrain |
| Description_FAB | Heavy duty tubular steel radius arms that correct caster while maximizing ground clearance |
| Description_FAB | Track bar relocation bracket and pitman arm maintain proper steering angles for improved handling |
| Description_FAB | Fabricated steel blocks provide level stance from front to rear |
| Description_FAB | Standard NX2 Nitro shocks with vehicle-specific valving for better control |
| Description_FAB | Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road |
| Description_MKT | Improve the ride on your 2017-2019 Ford F350 Dually “DRW” Super Duty gas truck with this 4-inch radius arm lift kit from BDS Suspension. Designed to improve stance performance and capability this kit includes everything necessary to set your dually truck up right with clearance for up to 37″ tires. |
| Description_MKT | Up front the lift kit includes gas-specific Pro-Ride coil springs heavy-duty replacement radius arms forged drop pitman arm and track bar bracket for steering correction sway bar relocation brake line brackets and precision tuned nitrogen charged shocks. |
| Description_MKT | In the rear this kit utilizes a high-strength fabricated lift block longer u-bolts brake line brackets and a matching set of NX2 Nitro or FOX Performance shocks. |
| Description_MKT | HD Radius Arms |
| Description_MKT | In place of the factory stamped steel radius arms BDS supplies a pair of high-strength tubular radius arms. These arms mount into the factory location and offer caster adjustment for a wide range of lift heights along with an OE-style rubber bushing at the frame mount for smooth quiet service-free operation. |
| Description_MKT | Pro-Ride Coil Springs |
| Description_MKT | A pair of full-length gas-specific Pro-Ride coil springs are supplied to provide the correct lift height and smooth predictable ride across various terrains. |
| Description_MKT | Steering Correction |
| Description_MKT | To optimize steering geometry once lifted a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle. |
| Description_SHO | Suspension lift kit |
| Description_DEF | Suspension Lift Kit |
